SWIFI-2KOCAM - 2K Outdoor Wi-Fi Spotlight Security Camera
Calculating...
Last updated:
Welcome to our SWIFI-2KOCAM - 2K Outdoor Wi-Fi Spotlight Security Camera resource hub! Whether you’re just starting or have been using it for a while, we’re here to help you get the most out of it. We’ve put together all the essential resources you might need, all in one place.
Feel free to explore each section below to find what you need. And if you have any questions, don’t hesitate to reach out to our support team. Let’s dive in!
Guides
- Quick Start Guide
- Swann Security App Manuals
Specs
| Model Number | SWIFI-2KOCAM |
|---|---|
| App | Swann Security |
| Software | NONE |
| Resolution | 2K |
| Viewing Angle | 100° |
| Best Use-Case | Continuous Power (plugged in), Indoor Monitoring, Outdoor Monitoring, Small Dark Area |
| Motion Detection | PIR + Motion (Up to 26ft / 8m) |
| Night Vision | Yes |
| Night Vision Range | Up to 100ft / 30m |
| Spotlight / Floodlight | Yes |
| Spotlight / Floodlight Range | Up to 65ft / 20m |
| Color option | white |
| Audio | Microphone, Speaker |
| Mic range | Up 16ft / 5m |
| Storage Options | cloud |
| Max Storage Capacity | NONE |
| Indoor/Outdoor | Indoor, Outdoor |
| IP Rating | IP66 |
| Power Connector | PoE (Power over Ethernet) |
| Power Source | 48V 0.35A |
| Wi-Fi Frequency | 2.4 GHz (Up to 65ft / 20m) |
| Operating Temperature | -22°F to 122°F / -30°C to 50°C |
| Dimension | 2.6” x 5.7” x 3.39" / 66mm x 145mm x 86mm |
| Lens Size | 2.5mm |
| Person Detection | Yes |
| Sound Detection | No |
| Siren (dB) | Yes - dB {no record} |
| Lumens | Up to 132 Lumens |
| SwannForce | No |
| GA, AA, IFTTT | AA, GA |
| Cloud Recording (Free) | 1 day |
| Color Temperature | NONE |
