Why is the LED Flashing on the NVW-600BATT Battery
If the LED is flashing on the NVW-600BATT battery while it is installed in the MaxRanger4K™ or AllSecure recorder, it usually means the battery temperature is higher than the normal charging range.
The NVW-600BATT serves as a backup power source for the recorder during power outages. Under normal use, the recorder should remain connected to its 12V power adapter so the battery stays charged and ready when it's needed.
Things to Know
Before troubleshooting the flashing LED, keep these points in mind:
- The recorder should remain connected to its 12V power adapter during normal operation.
- The NVW-600BATT automatically charges while the recorder is connected to AC power.
- The battery can also be charged through its USB-C port if needed.
- Charging may temporarily pause if the battery becomes too warm.
Why is the NVW-600BATT LED Flashing?
Short Answer: A flashing LED on the NVW-600BATT indicates that the battery temperature is higher than the recommended charging range.
Explanation:
This is a normal safety feature that helps protect the battery from overheating. If the battery becomes too warm, charging is temporarily paused until it cools to a safe temperature.
High battery temperatures can occur if the recorder is operating in a hot environment, is exposed to direct sunlight, or if the battery has recently experienced heavy use during a power outage.
Tips to Help Prevent This
- Keep the recorder in a cool, well-ventilated location.
- Avoid installing the recorder in direct sunlight or near heat sources.
- Ensure the recorder's ventilation openings are not blocked.
- Leave the recorder connected to its 12V power adapter so the battery remains fully charged and ready to provide backup power.
- If charging through USB-C, charge the battery in a cool environment and allow it to cool naturally if it has become warm.
Why It Matters
The flashing LED is a built-in protection feature that helps preserve battery health and charging safety. Since the NVW-600BATT is designed to provide backup power during an outage, keeping the recorder connected to its 12V power adapter ensures the battery is always charged and ready when AC power is lost.
Related Scenarios or Questions
Can I leave the recorder unplugged and run only on the battery?
No. The NVW-600BATT is intended as a backup power source, not the recorder's primary power supply.
Can I charge the NVW-600BATT using USB-C?
Yes. The USB-C port provides an alternative charging method when needed.
Why isn't the battery charging?
Charging may pause if the battery temperature is outside the recommended range. Allow it to cool before charging resumes.
What do the battery LED indicators mean?
- Red = charging
- Green = full charge
- Blinking = high temperature
Summary & Next Steps
If the NVW-600BATT LED is flashing, the battery is too warm to charge safely. Allow it to cool naturally and keep the recorder connected to its 12V power adapter so the battery remains charged and ready to provide backup power during an outage.
